#33e Serial I/O + Clock Module
Description
(This module was previously named #37b, with only some cosmetic differences)
- MC68B50 ACIA
- Crystal Oscillator, rec. 7.3728Mhz
- Address selectable
- 51 x 102 mm
- RC40 bus connector
Components
- PCB - 33e
- DIP-24 socket
- MC68B50 ACIA
- DIP-16 Socket
- 74HCT138N
- DIP-14 Socket
- 74HCT04N
- Crystal Oscillator, rec. 7.3728Mhz
- 2.2k resistors (3x)
- 100nF capacitors (4x)
- 2x8 pin male connector
- 6pin angled male adaptor (FTDI)
- pins and jumpers
- 1x40 pin angled male connector
